444 NA

444 NA

Peak torque
950 Nm
Litre Capacity
7,2
Gross Power
140kW
(188 hp)

Injection System: Mechanical
Emission Certification: Stage II / Tier 2
Cylinders: 4
Bore: 103 mm
Stoke: 132 mm
Rated Speed: 2200 rpm
Dry weight: 455 kg
Dimensions (LxWxH): 813,6 mm x 588,8 mm x 865,6 mm

POWERFUL POSSIBILITIES

POWERFUL POSSIBILITIES

Attention to detail means that every bracket, fastener, clip and guard is subjected to 1000’s of hours endurance testing both in the field, through and in the test cells. No matter if it’s crushing and screening, pumping, and irrigating or quasi-static equipment JCB Power Systems can provide the ultimate fully engineered solution for your machine.

WHAT MAKES OUR ENGINE BETTER?

WHAT MAKES OUR ENGINE BETTER?

  • Where required the innovative minimal aftertreatment solutions provides a compact installation for 56+ kW engines – ensuring a “no compromise” approach to machine design for our customers.
  • High Torque at Low Engine Speed – Power where you need it most. JCB Engines provide class leading torque at low engine speeds; allowing OEMs to design more efficient equipment with increased output.
  • Efficient – JCB engines have become renowned for fuel economy and productivity.
  • Advanced and highly developed combustion and air handling systems allow the most efficient operation whilst producing ultra-low, in-cylinder emissions.
  • Reduced Operating Costs – Up to 15% fuel savings, 500 hours standard oil service interval.
  • Versatile – Identical engine footprint and high degree of component commonality between engine ranges.

UNIQUE FEATURES

UNIQUE FEATURES

  • Tropical rated cooling packs
  • Integrated high efficiency air cleaner and pre-cleaner
  • Compact package for ease of installation
  • Constant power curve feature
  • Heavy duty 60Kw/80hp and low duty 10kW/13hp integrated PTO options as standard
  • Tier 4 / Stage V – Plug and Play Design
  • Integrated Wiring Harnesses
  • Two years unlimited hours warranty
